PART NO.

規(guī)格/編碼

ITEM NO.

品名型號(hào)

尺寸DIMENSIONS(mm)

Φd 2

B

L

ΦD

Φd

E

GCL1.5M3

GCL1.5-3

3.2

8

21

3.7

1.8

11

GCL1.5M4

GCL1.5-4

4.3

8

22

GCL1.5M5

GCL1.5-5

5.3

10

24

12

GCL1.5M6

GCL1.5-6

6.5

10

25

GCL2.5M3

GCL2.5-3

3.2

8

22

3.9

2.3

12

GCL2.5M4

GCL2.5-4

4.3

8

23

GCL2.5M5

GCL2.5-5

5.3

10

25

GCL2.5M6

GCL2.5-6

6.5

10

25

GCL2.5M8

GCL2.5-8

8.3

12.5

27.5

4.3

GCL4M4

GCL4-4

4.3

10

26

4.7

3

13

GCL4M5

GCL4-5

5.3

10

27

GCL4M6

GCL4-6

6.5

10

28

GCL4M8

GCL4-8

8.3

12.5

29

GCL6M4

GCL6-4

4.3

10

33.6

5.9

4

18.5

GCL6M5

GCL6-5

5.3

10

33.6

GCL6M6

GCL6-6

6.5

11

33.6

GCL6M8

GCL6-8

8.3

12.5

36.3

GCL6M10

GCL6-10

10.3

15

37.3

6.2

GCL10M5

GCL10-5

5.3

11

39

6.6

4.5

22

GCL10M6

GCL10-6

6.5

11

39

GCL10M8

GCL10-8

8.3

12.5

39

GCL10M10

GCL10-10

10.3

16

43.1

6.9

GCL10M12

GCL10-12

12.7

18

43.1

21

GCL16M5

GCL16-5

5.3

11

39.7

7.5

5.5

23

GCL16M6

GCL16-6

6.5

11

39.7

GCL16M8

GCL16-8

8.3

12.5

39.7

22

GCL16M10

GCL16-10

10.3

16

44.9

23

GCL16M12

GCL16-12

12.7

18

44.9

8.1

22

GCL25M5

GCL25-5

5.3

13

47.2

9.1

6.7

28

GCL25M6

GCL25-6

6.5

13

47.2

GCL25M8

GCL25-8

8.3

13

47.2

GCL25M10

GCL25-10

10.3

16

51.9

29

GCL25M12

GCL25-12

12.7

18

51.9

28

GCL25M14

GCL25-14

14.8

20

53.9

GCL35M5

GCL35-5

5.3

16

52.6

11

8.6

31

GCL35M6

GCL35-6

6.5

16

52.6

GCL35M8

GCL35-8

8.3

16

52.6

GCL35M10

GCL35-10

10.3

17

56.5

GCL35M12

GCL35-12

12.7

18

56.5

GCL35M14

GCL35-14

14.8

20

58.5

GCL35M16

GCL35-16

16.5

23

60.5

GCL50M5

GCL50-5

5.3

18

56

12.4

9.5

32

GCL50M6

GCL50-6

6.5

18

56

GCL50M8

GCL50-8

8.3

18

56

GCL50M10

GCL50-10

10.3

18

59

PART NO.

規(guī)格/編碼

ITEM NO.

品名型號(hào)

尺寸DIMENSIONS(mm)

Φd 2

B

L

ΦD

Φd

E

GCL50M12

GCL50-12

12.7

19

59

12.4

9.5

32

GCL50M14

GCL50-14

14.8

21

67.8

34

GCL50M16

GCL50-16

16.5

23

67.8

GCL70M5

GCL70-5

5.3

22

67.4

15

12

36.5

GCL70M6

GCL70-6

6.3

22

67.4

GCL70M8

GCL70-8

8.3

22

67.4

GCL70M10

GCL70-10

10.3

22

67.4

GCL70M12

GCL70-12

12.7

22

67.4

GCL70M14

GCL70-14

14.8

22

70

GCL70M16

GCL70-16

16.5

24

70

35

GCL95M8

GCL95-8

8.3

25

69.7

17

13.4

37.5

GCL95M10

GCL95-10

10.3

25

69.7

GCL95M12

GCL95-12

12.7

25

69.7

GCL95M14

GCL95-14

14.8

25

73.3

GCL95M16

GCL95-16

16.5

25

73.3

GCL95M20

GCL95-20

20.9

28

73.3

34.5

GCL120M8

GCL120-8

8.3

27.5

75

19

15

38

GCL120M10

GCL120-10

10.3

27.5

75

GCL120M12

GCL120-12

12.7

27.5

75

GCL120M14

GCL120-14

14.8

27.5

79

GCL120M16

GCL120-16

16.5

27.5

79

GCL120M20

GCL120-20

20.9

27.5

79

GCL150M10

GCL150-10

10.3

30.5

82

21.2

16.5

42

GCL150M12

GCL150-12

12.7

30.5

82

GCL150M14

GCL150-14

14.8

30.5

82

GCL150M16

GCL150-16

16.5

30.5

86.4

GCL150M20

GCL150-20

20.9

30.5

86.4

GCL185M10

GCL185-10

10.3

34

88

23

19

45

GCL185M12

GCL185-12

12.7

34

88

GCL185M14

GCL185-14

14.8

34

88

GCL185M16

GCL185-16

16.5

34

91.2

GCL185M20

GCL185-20

20.9

34

91.2

GCL240M10

GCL240-10

10.3

38.6

106.4

26.5

21

53

GCL240M12

GCL240-12

12.7

38.6

106.4

GCL240M14

GCL240-14

14.8

38.6

106.4

GCL240M16

GCL240-16

16.5

38.6

106.4

GCL240M20

GCL240-20

20.9

38.6

106.4

GCL300M12

GCL300-12

12.7

43.8

113

30

24.5

57

GCL300M14

GCL300-14

14.8

43.8

113

GCL300M16

GCL300-16

16.5

43.8

113

GCL300M20

GCL300-20

20.9

43.8

113

GCL400M12

GCL400-12

12.7

50

119

35

27

59

GCL400M14

GCL400-14

14.8

50

119

GCL400M16

GCL400-16

16.5

50

119

GCL400M20

GCL400-20

20.9

50

119
